Specifications
Platform | Desktop |
Market Segment | Mainstream Desktop |
Product Family | AMD Ryzenâ„¢ Processors |
Product Line | AMD Ryzenâ„¢ 5 Desktop Processors |
Consumer Use | Yes |
Former Codename | "Vermeer" |
Architecture | "Zen 3" |
# of CPU Cores | 6 |
Multithreading (SMT) | Yes |
# of Threads | 12 |
Max. Boost Clock | Up to 4.4GHz |
Base Clock | 3.5GHz |
L1 Cache | 384KB |
L2 Cache | 3MB |
L3 Cache | 32MB |
Default TDP | 65W |
Processor Technology for CPU Cores | TSMC 7nm FinFET |
Processor Technology for I/O Die | 12nm (Globalfoundries) |
CPU Compute Die (CCD) Size | 74mm² |
I/O Die (IOD) Size | 125mm² |
Package Die Count | 2 |
Unlocked for Overclocking | Yes |
CPU Socket | AM4 |
Socket Count | 1P |
Supporting Chipsets | X570,X470,X370,B550,B450,B350,A520 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
Thermal Solution (PIB) | AMD Wraith Stealth |
Max. Operating Temperature (Tjmax) | 90°C |
*OS Support | Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. |
Connectivity | |
USB Type-C® Support | Yes |
Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
Native USB 2.0 (480Mbps) Ports | 0 |
Native SATA Ports | 2 |
PCI Express® Version | PCIe 4.0 |
Native PCIe® Lanes (Total/Usable) | 24/20 |
Additional Usable PCIe Lanes from Motherboard |
|
NVMe Support | Boot, RAID0, RAID1, RAID10 |
System Memory Type | DDR4 |
Memory Channels | 2 |
Max. Memory | 128GB |
System Memory Subtype | UDIMM |
System Memory Specification | Up to 3200MHz |
Max Memory Speed |
|
ECC Support | Yes (Requires mobo support) |
Graphics Capabilities | |
Integrated Graphics | No |
Graphics Model | Discrete Graphics Card Required |
Key Features | |
Supported Technologies |
|
Warranty | 3 Years |
Note | *** Features, Price, Specifications are subject to change without notice. |
Weight | 1 kg |
---|---|
Product Type | Gaming |
Brand | AMD |
CPU Cores | 6 |
Processor Series | Ryzen 5, Ryzen 5000 |
Socket | AM4 |
CPU Threads | 12 |
Processor Model | Ryzen 5 5600 |
Warranty | 3 Years |
EAN Code | 8592978371814 |
