Phanteks NV9 MKII D-RGB Clear Tempered Glass Steel E-ATX Full Tower Desktop Cabinet (Satin Black)
Sale!52%
– Full-Tower E-ATX Form Factor
– Supports ATX Backside Connector Motherboards
– Dual-Chamber Design with Bottom Fan Bracket
– 2-Sided Column-less Glass Panel Design
– Includes D-RGB Dual-Channel Controller Hub
Original price was: ₹39,990.00.₹19,199.00Current price is: ₹19,199.00. (Inclusive of GST)
Out of stock
Shipping Policy
Order Will Be Shipped Within 24-48 Working Hours After the Order is Processed. Shipping Partners : FedEx, Delhivery, XpressBees, Gati, BlueDart, Ecom Express (Depending on Availability at Your Pincode), Green Apple Compunet DOES NOT Have any Control over Operations of Shipping Partners. Delivery dates are estimates Provided By Shipping Partners. Shipping Partners are solely responsible for any kind of Delays. Loss or damage occured during shipping is Green Apple Compunet Responsibility. You Must Leave a Remark During Delivery to Delivery Guy About Damaged Box or Package, and Make an Un-cut Unboxing Video of the Package. You must notify Green Apple Compunet of damaged or missing items from your order within 24-hours of receiving your package.
Get it by
Jul 27 Jul 31
Guaranteed safe & secure checkout
Description
SPECIFICATIONS
Additional information
Reviews (0)
Q & A
Phanteks NV9 MKII D-RGB Clear Tempered Glass Steel E-ATX Full Tower Desktop Cabinet (Satin Black) (PH-NV923TG_DBK02
Feature
Here’s a structured WordPress-ready format for the Phanteks NV9 product description, optimized for readability and SEO:
Phanteks NV9: A True Showcase of Performance
Key Features
1. Stunning Showcase Design
-
Near-seamless glass panels (front and side) highlight components with minimal visual interruption.
-
Motherboard-centric layout with a strong outer steel frame to accentuate hardware.
-
Clean rear design eliminates traditionally messy cable management, allowing placement flexibility.
2. Uncompromising Cooling Performance
-
Fan Support:
-
12×140mm or 11×120mm fans (configurable as Top: 3, Side: 4/3, Bottom: 3, Rear: 2).
-
-
Radiator Support:
-
Top: 420mm (140mm) or 360mm (120mm).
-
Side: 420mm (140mm) or 480mm (120mm).
-
Bottom: 420mm (140mm) or 360mm (120mm).
-
Rear: 280mm (140mm) or 240mm (120mm).
-
-
Dedicated GPU cooling via bottom intake with 65mm clearance and ultra-fine mesh panels.
3. Clean Aesthetics & Cable Management
-
Modular I/O panel (USB-C 3.1, 2×USB-A 3.0) can be relocated to the rear for a pristine front view.
-
Hidden cable routing via grommets and velcro combs for a zero-cable setup.
-
Rear door swings open for easy access to components.
4. Advanced Features
-
Versatile GPU support bracket prevents sag and secures the GPU.
-
Removable fan brackets for hassle-free installation.
-
Integrated D-RGB lighting (no software required) with motherboard sync compatibility (Asus AURA, MSI Mystic, etc.).
5. Storage Flexibility
-
6×2.5” SSDs or 3×3.5” HDDs behind the motherboard.
-
Optional CableMod presets for custom cable management.
Why Choose the NV9?
-
Striking design: Near-seamless glass panels and motherboard-centric layout.
-
Extreme cooling: Supports up to triple 420mm radiators and 12×140mm fans.
-
Convenient features: Modular I/O, hidden cable routing, and GPU support bracket.
-
Premium build quality: Reinforced steel frame with tempered glass panels.
Optional Upgrades
-
NV9 Premium D-RGB Kit: Add smooth RGB strips around the glass window.
-
CableMod Presets: Custom cable lengths and Revolt PSU kits for a cableless build.
SPECIFICATIONS
| Brand | Phanteks |
| Series | NV9 Series |
| Model | NV9 MKII Black (PH-NV923TG_DBK02) |
| Physical Details | |
| Colour | Black |
| Materials | Aluminium |
| Steel | |
| Tempered Glass | |
| Windowed Side Panel | Columnless Modular Tempered Glass |
| Front I/O | 1x USB 10Gbps Type-C Port |
| 2x USB 5Gbps Type-A Ports | |
| 1x 3.5mm Combination Audio Jack | |
| Motherboard Support | SSI-CEB, E-ATX (280mm Width), ATX, Micro-ATX, Mini-ITX motherboards |
| Expansion Slots | 8x Horizontal PCI Slots |
| Drive Bays | 3x 2.5"/3.5" Combo Drive Bays (24mm height limit) |
| 6x 2.5" Drive Bays (2x only if 3x 3.5" bays are in use) | |
| PSU Support | ATX |
| Dimensions | 575 x 615 x 280mm (D x H x W) |
| Weight | 19.52kg |
| Pre-Installed Fans | |
| Side | N/A |
| Bottom | N/A |
| Rear | N/A |
| Fan Support | |
| Top | 3x 120mm or 3x 140mm |
| Side | 4x 120mm or 3x 140mm |
| Bottom | 3x 120mm or 3x 140mm |
| Rear | 2x 120mm or 2x 140mm |
| Radiator Support | |
| Top | 120 / 240 / 280 / 360 / 420mm radiator support |
| Side | 120 / 240 / 280 / 360 / 420mm radiator support |
| Bottom | 120 / 240 / 280 / 360 / 420mm radiator support |
| Rear | 120 / 240 / 280mm radiator support |
| Radiator Clearances | |
| Top | 515 x 154mm (L x W) |
| Side | 525 x 154mm (L x W) |
| Bottom | 480 x 162mm (L x W) |
| Rear | 325 x 154mm (L x W) |
| Clearance | |
| CPU Cooler Height Limitation | Up to 205mm |
| GPU Length Limitation | Up to 490mm (205mm GPU width) |
| PSU Length Limitation | Up to 210mm |
| Cable Management | Yes, behind motherboard tray |
| General | |
| Dust Filters | Side and Rear full-length integrated filters |
| Bottom mounted removable mesh filter | |
| Chassis Lighting | Yes, Phanteks D-RGB no-software controller with JST connector |
| D-RGB Control Buttons (Mode, Colour, Speed, Channel) on front panel | |
| D-RGB Controller includes dual channel RGB signaling, requires SATA power, 7A per channel or 4A per port | |
| Compatible with major 3-pin ARGB headers and motherboard software | |
| Boxed Accessories | 1x Dual D-RGB Controller |
| 1x Top LED Cover | |
| 1x Side LED Cover | |
| 1x Front IO-Module | |
| 1x Storage/Cable bracket | |
| 1x Storage Bracket | |
| 1x GPU Support Bracket | |
| 2x Airflow Covers | |
| 1x Microfiber Cloth | |
| 6x Zip ties | |
| 1x Screw Assortment Box | |
| 34x MB/SSD Screws | |
| 4x Thumb Screw | |
| 9x HDD Screw | |
| 1x Standoff Removal Tool | |
| 1x MB stand-off | |
| 4x PSU Screw | |
| 1x Extra R-Side Panel Screw | |
| Warranty Information | |
| Warranty | 5 Year Limited Warranty |
| Weight | 5 kg |
|---|---|
| Brand | Phanteks |
| Product Type | Gaming |
| color | Black |
| Case Form Factor | Full Tower |
| Motherboard Size | ATX, E-ATX, ITX, mATX, Mini ITX |
| Radiator Size | 120mm, 240mm, 280mm, 360MM, 420mm, 480mm |
| Warranty | 5 Years |
