Phanteks NV5 MK2 E-ATX Mid-Tower Tempered Glass Cabinet (White)
Sale!52%
- Form Factor: Mid tower
- White
- Supported motherboard form factors: ATX, Micro-ATX, Mini-ITX, E-ATX
- Brand: Phanteks
- Size: Mid tower
Original price was: ₹22,990.00.₹10,950.00Current price is: ₹10,950.00. (Inclusive of GST)
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Interpretation and Definitions
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Get it by
Apr 21 Apr 25
Guaranteed safe & secure checkout
Description
Specifications
Additional information
Reviews (0)
Q & A
Phanteks NV5 MK2 E-ATX Mid-Tower Cabinet, Rear-Connect MB Support, Integrated D/A-RGB Lighting, Seamless Tempered Glass Design, 8x Fan Positions, White
Feature
- Create a picture-perfect PC with a seamless glass design.
- Support for the new Rear-Connect Mainboards for a zero-cable build.
- Increased chassis width to support wider GPUs and PCIe cables.
- Premium build quality throughout the strong and reinforced outer frame.
- High Airflow Performance with fine mesh, dust filter and 8x 120mm fan positions.
- Ready for ultimate water-cooling configurations with dual 360 radiator support.
- Integrated D-RGB lighting in the PSU Cover with built-in D-RGB Controller that works out of the box and can sync with the mainboard.
/11-854-137/1.jpg)
Here’s a structured WordPress-ready format for the Phanteks NV5 MKII product description:
Phanteks NV5 MKII: Performance with a View
Meet the NV5 MKII Mid-Tower Chassis
The NV5 MKII redefines mid-tower design with its stunning near-seamless glass panels, support for 8×120mm fans, and dedicated space for 360mm radiators on the top and side. Engineered for optimal cooling and aesthetics, it features:
-
Dedicated bottom GPU fan for enhanced cooling.
-
Spacious interior to accommodate modern GPUs and cables.
-
PSU cover that opens for effortless cable management.
-
DRGB lighting system with customizable effects and motherboard sync.
Key Features
1. Unobstructed System View
-
Near-seamless glass panels showcase components with minimal visual interruption.
-
Strong steel outer frame and reinforcement bracket ensure durability.
-
Ultra-fine mesh on top/side panels for high airflow and dust filtration.
2. Performance-Driven Design
-
Removable PSU cover for easy cable access.
-
Dedicated GPU fan delivers direct airflow to the GPU from below.
-
Increased chassis width supports wider GPUs and 12VHPWR cables.
-
Versatile GPU support bracket prevents sag and secures the GPU.
3. Future-Ready Compatibility
-
Supports rear-side connector mainboards (MSI Project Zero, ASUS BTF).
-
Dual 360mm radiator mounts (top and side) for extreme cooling.
-
8×120mm fan positions for ultimate airflow.
4. Storage & Cable Management
-
4×2.5” SSDs or 3×3.5” HDDs.
-
Cover doors and velcro cable combs for tidy cable routing.
5. Enhanced Lighting
-
New-gen D-RGB controller with refined effects (no software required).
-
Integrated PSU cover lighting syncs with motherboard headers.
About Phanteks
Phanteks is committed to developing top-quality products for PC enthusiasts. The NV5 MKII exemplifies this mission with its blend of innovation, performance, and sleek design.
Why Choose the NV5 MKII?
-
Sleek aesthetics with near-seamless glass.
-
Optimal cooling for high-performance builds.
-
Convenient features like easy cable management and GPU support.
-
Future-proof design compatible with the latest hardware.
Specifications
| Brand | Phanteks |
|---|---|
| Model | NV5 MK2 |
| Part Number | PH-NV523TG_DMW02 |
| Type | ATX Mid Tower |
| Color | Black |
| Case Material | Steel / Tempered Glass |
| With Power Supply | No |
| Motherboard Compatibility | ATX, Rear-Connect ATX, micro-ATX, mini-ITX, E-ATX (up to 280mm without GPU Support Bracket) |
| Side Panel Window | Front and Side Tempered Glass |
| LED | RGB |
| Internal 3.5" Drive Bays | 3 |
| Internal 2.5" Drive Bays | 4 |
| Expansion Slots | 7 |
| Front Ports | 2 x USB 3.0, USB-C Gen 2, 1 x Audio |
| Fan Options | Bottom - 1 x 120mm / Rear - 1 x 120mm / Side - 3 x 120mm / Top - 3 x 120mm |
| Radiator Options | Rear - Up to 120mm / Side - Up to 360mm / Top - Up to 360mm |
| Max GPU Length | 440 mm Length, 170 mm Width |
| Max CPU Cooler Height | 180 mm |
| Max PSU Length | 230 mm |
| Dimensions (H x W x D) | 528 x 239 x 477 mm / 20.8" x 9.4" x 18.8" |
| Weight | 11.28 kg / 24.9 lbs. |
| Package Content | NV5 Chassis 1 x D-RGB Controller 1 x Storage Door 1 x GPU Support BracketAccessory Box 6 x Zip ties 22 x MB/SSD Screw 4 x Thumb Screw 12 x HDD+Case Screw 1 x Standoff Removal Tool 1 x MB stand-off 4 x PSU Screw |
| Weight | 5 kg |
|---|---|
| Brand | Phanteks |
| Product Type | Gaming |
| color | White |
| Case Form Factor | Mid Tower |
| Motherboard Size | ATX, E-ATX, ITX, mATX, Mini ITX |
| Radiator Size | 120mm, 240mm, 280mm, 360MM |
| Warranty | 5 Years |
| EAN Code | 0886523303473 |
