Gigabyte GeForce RTX 5060 GAMING OC Graphics Card
Based on the Blackwell architecture, the Gigabyte GeForce RTX 5060 GAMING OC Graphics Card brings the power of real-time ray tracing and AI to your PC games. Play your favorite titles at a high resolution and high frame rates with 8GB of GDDR7 VRAM and a 128-bit memory interface, which offer improved performance over the previous Ada Lovelace-based generation.


The front panel of the card features DisplayPort 2.1 and HDMI 2.1 outputs. But the RTX 5060 is not just about high-performance gaming. Computationally intensive programs can utilize the GPU’s 3840 cores to accelerate tasks using CUDA and other APIs. This graphics card features up to 2595 MHz overclocked speeds.
- Â Powered by the NVIDIA Blackwell architecture and DLSS 4
- Â Powered by GeForce RTXâ„¢ 5060
- Â Integrated with 8GB GDDR7 128bit memory interface
- Â WINDFORCE cooling system
- Â Hawk fan
- Â Server-grade Thermal conductive gel
- Â RGB lighting
- Â Dual BIOS (Performance / Silent)
- Â Reinforced structure
SPECIFICATIONS
<>tdTexture Units
Feature | Specification |
---|---|
Brand | Gigabyte |
Model | GeForce RTX 5060 GAMING OC |
Chipset | NVIDIA GeForce RTX 5060 |
Architecture | NVIDIA Blackwell |
Memory Size | 8GB GDDR7 |
Memory Type | GDDR7 |
Memory Interface | 128-bit |
Memory Bandwidth | 448 GB/s |
Base Clock | 2280 MHz |
Boost Clock | 2550 MHz |
Shader Units | 3840 |
Streaming Multiprocessors | 30 |
Ray Tracing Cores | 30 |
Tensor Cores | 120 |
Render Output Units | 48 |
Power Consumption | 145W |
Power Connector | 1 x 8-Pin |
Cooling System | WINDFORCE with Hawk fans, server-grade thermal conductive gel, composite copper heat pipes, copper plate, 3D active fans, and screen cooling |
Output Ports | 1x HDMI 2.1b, 3x DisplayPort 2.1b |
Max. Resolution | 7680x4320 |
DirectX Support | 12_2 (Ultimate) |
Dimensions (LxHxW) | 281 mm x 117 mm x 40 mm |
Slot Width | 2 PCIe-Slots |
Release Date | May 2025 |
Warranty | 3 Years |
Weight | 1 kg |
---|---|
Brand | Gigabyte |
Product Type | Normal |
color | Black |
GPU Series | RTX 50 Series |
GPU Chipset | NVIDIA Geforce |
GPU Memory Size | 8GB |
Memory Series | GDDR7 |
Warranty | 3 Years |
