Gigabyte GeForce RTX 5060 Aero OC 8GB GDDR7
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- Powered by GeForce RTXâ„¢ 5060
- Integrated with 8GB GDDR7 128bit memory interface
- Gigabyte WINDFORCE cooling system
- RGB lighting
- Dual BIOS (Performance / Silent)
- Reinforced structure
SPECIFICATIONS
Feature | Specification |
---|---|
Brand | Gigabyte |
Model | GeForce RTX 5060 Aero OC 8GB GDDR7 |
Chipset | NVIDIA GeForce RTX 5060 |
Architecture | NVIDIA Blackwell |
Memory Size | 8GB GDDR7 |
Memory Type | GDDR7 |
Memory Interface | 128-bit |
Memory Bandwidth | 448 GB/s |
Base Clock | 2280 MHz |
Boost Clock | 2595 MHz |
Shader Units | 3840 |
Streaming Multiprocessors | 30 |
Ray Tracing Cores | 30 |
Tensor Cores | 120 |
Render Output Units | 48 |
Texture Units | 120 |
Power Consumption | 145W |
Power Connector | 1 x 8-Pin |
Cooling System | WINDFORCE with Hawk fans, server-grade thermal conductive gel, composite copper heat pipes, copper plate, 3D active fans, and screen cooling |
Output Ports | 1x HDMI 2.1b, 3x DisplayPort 2.1b |
Max. Resolution | 7680x4320 |
DirectX Support | 12_2 (Ultimate) |
Dimensions (LxHxW) | 281 mm x 117 mm x 40 mm |
Slot Width | 2 PCIe-Slots |
Release Date | May 2025 |
Warranty | 3 Years |
Weight | 1 kg |
---|---|
Brand | Gigabyte |
Product Type | Normal |
color | White |
GPU Series | RTX 50 Series |
GPU Chipset | NVIDIA Geforce |
GPU Memory Size | 8GB |
Memory Series | GDDR7 |
Warranty | 3 Years |
