Gigabyte AORUS ELITE 1000W 80 PLUS Platinum Modular ATX Power Supply (Black)
Sale!61%
- 1000W Single +12V Rail
- 120mm Fluid Dynamic Bearing Fan
- Intel ATX 3.1 and PCIe 5.0 Ready
- AORUS Magnetic Plate
- 80 Plus Platinum Certified
Original price was: ₹40,499.00.₹15,989.00Current price is: ₹15,989.00. (Inclusive of GST)
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Interpretation and Definitions
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Get it by
May 18 May 22
Guaranteed safe & secure checkout
Description
SPECIFICATIONS
Additional information
Q & A
Gigabyte AORUS ELITE 1000W 80 PLUS Platinum Modular ATX Power Supply (Black)
GIGABYTE AORUS ELITE 1000W 80 PLUS Platinum Certified – PCIe5.1 Ready – ATX3.1 – Fully Modular Power Supply (GP-AE1000PM PG5)
Feature
KEY FEATURE
- Gigabyte ATX 3.1 and PCIe Gen 5.1 ready
- 80 PLUS Platinum certified
- 100% Japanese capacitors
- 120mm smart Fluid Dynamic Bearing (FDB) fan
- Compact design
- Fully modular design
- Powerful single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection




ATX 3.1 and PCIe Gen 5.1 ready
The AE1000PM PG5 ICE can sustain power excursions of up to 3 times the GPU power and 2 times the total power. It’s fully compliant with the Intel ATX 3.1 standard, supporting up to 200% power excursions and achieving 70% efficiency at low loads. Additionally, the included high-quality, native 16-pin cable ensures compatibility with PCIe Gen 5 graphics cards, delivering up to 600 watts of power.
AORUS magnetic plate design
The unique AORUS magnetic plate can be attached to different sides of the power supply based on the user’s preference, presenting the best visual effect from any angle. Additionally, while the plate being moved on the case, its neon color printing with metallic sheen creates solid and hollow special effects for the AORUS logo.
80 PLUS Platinum certified
80 Plus Platinum certified ensures to deliver 92% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
100% Japanese capacitors
All capacitors are high quality Japanese capacitors, to produce the efficient performance and to ensure the longer reliability.
120mm smart Fluid Dynamic Bearing (FDB) fan
High-performance Fluid Dynamic Bearing fan uses oil film shock absorption technology to effectively reduce noise, making it quieter than conventional sleeve fan and providing more than twice the lifespan. In addition, the fan speed is adjusted according to the automatic power detection and stops when the system is idle or under low load (less than 50% load).
FAN
ACOUSTIC
Compact design
GIGABYTE’s engineering expertise in heat dissipation and material selection has shrunk the length of the power supply to an impressive 140 mm, ensuring compatibility with even space-constrained chassis.
Fully modular design
All the flat cables are modular design. Installing only the cables you need to reduce clutter, to increase the airflow and to improve the chassis thermal performance.
Powerful single +12V rail
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
Protection
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
SPECIFICATIONS
| Brand | GIGABYTE |
| Model | GP-AE1000PM PG5 |
| Type | ATX (ATX 3.1 Compatible) |
| Maximum Power | 1000W |
| Fan | 120mm Fluid Dynamic Bearing (FDB) Fan |
| PFC | Active PFC (>0.9 typical) |
| Efficiency | 92% at typical load (80 PLUS PLATINUM Certified) |
| Protection | OVP/OPP/SCP/UVP/OCP/OTP |
| Input Voltage | 100-240V |
| Input Frequency Range | 50-60Hz |
| Input Current | 15-6.5A |
| MTBF | >100,000 hours |
| Connectors | 1 x 12VHPWR (12+4) PCIe
1 x 24 pin (20+4) ATX 3 x 4 pin Peripheral 6 x 8 pin (6+2) PCIe 8 x SATA |
| Cable Spec | ATX/MB: 650mm
CPU/EPS: 700mm x 2 PCI-e 16 Pin: 700mm PCI-e 6+2 Pin: 650mm+150mm x 2, 750mm x 2 SATA: 600mm+150mm+150mm+150mm x 2 4 Pin Peripheral: 500mm+150mm+150mm+150mm |
| Modularity | Full Modular |
| Power Good Signal | 100-150ms |
| Hold-up Time | >16ms |
| Weight | 1 kg |
|---|---|
| Brand | Gigabyte |
| color | Black |
| Product Type | Gaming |
| PSU Certification | Platinum |
| Warranty | 10 Years |
| Wattage | 1000W |
Q & A
Ask a question
Gigabyte AORUS ELITE 1000W 80 PLUS Platinum Modular ATX Power Supply (Black)
Your question
* Question is required
Name
* Name is required
Email
* Email is required
There are no questions yet
Related Products
Sale!46%
Ant Esports RX550 80 Plus Bronze Gaming PSU
Original price was: ₹4,999.00.₹2,675.00Current price is: ₹2,675.00. (Inclusive of GST)- ✓ Official Brand Warranty
- ✓ Delivery All Over India
- ✓ Easy Installment Options
Sale!15%
Corsair AX1600i Digital ATX Power Supply
Original price was: ₹54,990.00.₹46,900.00Current price is: ₹46,900.00. (Inclusive of GST)- ✓ Official Brand Warranty
- ✓ Delivery All Over India
- ✓ Easy Installment Options
Sale!58%
Gigabyte UD850GM PG5 850W 80 PLUS Gold Modular Power Supply (White)
Original price was: ₹22,999.00.₹9,699.00Current price is: ₹9,699.00. (Inclusive of GST)- ✓ Official Brand Warranty
- ✓ Delivery All Over India
- ✓ Easy Installment Options
Sale!45%
Gigabyte P650G 650 Watt 80 Plus Gold
Original price was: ₹9,000.00.₹4,949.00Current price is: ₹4,949.00. (Inclusive of GST)- ✓ Official Brand Warranty
- ✓ Delivery All Over India
- ✓ Easy Installment Options
Sale!68%
Gigabyte P650SS ATX 3.0 650 Watt 80 Plus Silver Power Supply (White)
Original price was: ₹14,999.00.₹4,789.00Current price is: ₹4,789.00. (Inclusive of GST)- ✓ Official Brand Warranty
- ✓ Delivery All Over India
- ✓ Easy Installment Options
Sale!57%
Ant Esports VS500L SMPS
