CP PLUS 2MP Full HD IR Network Dome Camera with Fixed Lens – CP-UNP-D2521L10-DAQ
RAM & SSD prices are highly volatile. Please confirm stock and price before placing your order.
₹48,999.00 Original price was: ₹48,999.00.₹34,729.00Current price is: ₹34,729.00. (Inclusive of GST)
- 1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters)
- Max. 2MP (1920 × 1080)@1–25fps
- Powerful 25x Optical and 16x Digital zoom
- WDR(120dB), Day/Night(ICR), 2D NR/ 3D NR, Defog, AWB, AGC, BLC, HLC
- Up to 300 Presets, 5 Scan, 8 Tour, 5 Pattern
- Support Starlight Technology
- IR Range of 100 Mtr., IP66
- Mobile Software: iCMOB, gCMOB
- CMS Software: KVMS Pro Lite, EVMS Pro
In stock
CP PLUS 2MP Full HD IR Network Dome Camera with Fixed Lens – CP-UNP-D2521L10-DAQ
System Overview
This Series has been developed mainly to present the
PTZ cameras that have been designed to submerge
into the surface and keep a secret eye on the scene.
The Lite Series obeys the notion of stealth
surveillance, while at the same time, expanding the
image quality through using the wide dynamic range
technology, which provides a balanced lighting and
clears distortions.

CTC Technology:
CP PLUS Trusted Core Technology is a multi-layered security
architecture that brings together the best of cyber security
practices and technological intelligence. It is not just an enhancement; it is a complete redefinition of how surveillance
should function in today’s digital landscape – more intelligent,
more secure, and more reliable than ever before.
Wide Dynamic Range (WDR)
When a scene is partly dark and partly bright, that is the dynamic range that distorts images due to this difference in the
lighting. WDR technology provides you balanced lighting for a
clear and vivid image throughout the day. WDR technology can
be installed at entry/exit points of any building structure,
jewelers shops, outdoor location among so many other places.
True Day/Night (ICR)
When the scene is too dark, the image is captured by illuminating an infrared light through the camera onto the scene
that greatly helps with making the scene visible for the lens.
It delivers color images during the day and automatically
switches to the monochrome feature as the scene darkens.
Starlight Technology
This camera is widely used to provide sharper and
clear-er picture quality with the help of its exceptional
star-light sensitivity as the camera improves night vision
in low light conditions. This technology is useful in
conditions with extremely low light as the starlight
technology turns almost completely dark images into
those of clear colors.
About CP PLUS
The brand that is on its way to lead the world when it comes to the security and surveillance industry, CP PLUS, keeps
bombarding the market with the most reliable range of products that have been designed carefully and methodically
to automate the whole surveillance and security process, no matter how big your premises are.
It was the initiative to help the public in the area where they are the most vulnerable and to empower the sense of safety
in our hearts that had conceptualized CP PLUS . And embarking on its mission to make the world a safer and more secure
place has taken the brand’s journey to unprecedented levels even when compared to international competitors.

| Image Sensor | 1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters) |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Electronic Shutter | 1/1 s–1/30,000 s |
| Max. Aperture | F1.6–F3.5 |
| RAM | 512 MB |
| ROM | 256 MB |
| Minimum Illumination | 0.005 [email protected] (Color, 30 IRE), 0.0005 [email protected] (B/W, 30 IRE), 0 lux (IR light) |
| White Balance | Auto, Indoor, Outdoor, Tracking, Manual, Sodium lamp, Natural light, Street lamp |
| S/N Ratio | ≥55 dB |
| Focus Control | Auto, Semi-auto, Manual |
| Lens | 4.8 mm–120 mm |
| Close Focus Distance | 0.1 m–1.5m |
| Angle of View | H: 60.6°–3.2°; V: 34.1°–1.8°; D: 69.4°–3.7° |
| Iris Control | Auto, Manual |
| DORI Distance | 1655.2 mm (Detect), 653.8 mm (Observe), 331.0 mm (Recognize), 165.5 mm (Identify) |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| IR Control | Zoom Prio, Manual, Auto |
| IR Number | 3 IR |
| Day/Night | Auto (ICR)/Color/B/W |
| IR | IR Range of 100 Mtr. |
| Video Format | PAL |
| Bit Rate | H265: 86 kbps–5632 kbps, H264: 256 kbps–8192 kbps |
| Overlay | Channel Title, Time Title, OSD Info (PTZ Coordinate, Zoom, North, Pattern, Temperature, Preset, Location, Input Text, Text Alignment), Font Properties, Custom Title, Exception Overlay |
| Gain Control (AGC) | Auto, Manual |
| Resolution | 2MP (1920 × 1080), 720p (1280 × 720), D1 (704 × 576),CIF (352 x 288) |
| Pan/Tilt Angle | Pan: 0° to 360° endless, Tilt: –15° to +90°, auto flip 180° |
| Optical Zoom | 25× |
| Digital Zoom | 16x |
| Image Rotation | 180° |
| Defog | Electronic |
| Special Features | Up to 300 Presets, 5 Pattern, 8 (up to 32 presets per tour) Tour, 5 Scan |
| Frame Rate | Main stream: 2MP (1920 × 1080)@1–25fps, 720p, D1@1–25fps Sub stream 1: D1/CIF@1–25fps, Sub stream 2: 2MP (1920 × 1080)@1–25fps, 720p, D1@1–25fps Sub stream 3: D1/CIF@1–25fps, Sub stream 4: D1/CIF@1–25fps |
| Bit Rate Control | CBR/VBR |
| IMD | Support |
| Noise Reduction | 2D NR/3D NR |
| Stream Capability | Penta stream |
| Idle Motion | Pattern, Preset, Scan, Tour |
| Protocol | IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTP, RTSP, RTCP, RTMP, SMTP V3, SFTP, DHCP, DNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NAS, PPPoE, SNMP, Auto Connect, TLS v1.2 and v1.3, ONVIF (Profile S, Profile G, Profile T), InstaOn |
| Device Search Tool | IP finder |
| OTA (Over-The-Air) | Support |
| SDK and API | Support |
| Power-off Memory | Support |
| Manual Speed | Pan: 0.1°–80°/s, Tilt: 0.1°–80/s |
| Preset Speed | Pan: 80°/s, Tilt: 80°/s |
| Event Alarm | Motion Detection, Defocus Detection, Disk Full, Disk Error, Video Tampering, External Alarm, Security Warning, Audio Detection, AI Event |
| Alarm Linkage | Capture, Recording, Send email, Preset, Tour, Pattern, Alarm digital output |
| Privacy Mask | Support |
| IVS (Perimeter Protection) | Crossing virtual fence, Tripwire, Intrusion, Abandoned Object, Fast Moving, Parking Detection, Crowd Gathering, Missing Object, Loitering Detection, Face Detection, IMD |
| Cyber Security | AES 256-bit Encryption, Configuration encryption, Trusted execution, Digest, Security logs, WSSE, Account lockout, Syslog, Video encryption, 802.1x, Allow list/Block list, HTTPS, Trusted upgrade, Trusted boot, Firmware encryption |
| Audio In | 1 Channel |
| Audio Out | 1 Channel |
| Alarm IN | 2 (on-off value input: 0–5 VDC) |
| Alarm Out | 1 Channel |
| Reset Button | Support |
| Weatherproof Standard | IP66, TVS 6000V lightning proof, Surge protection, Voltage transient protection |
| Storage | SFTP, NAS, Mirco SD card (Max. 512GB) |
| Certificates | ISO 9001: 2015, ISO 20000-1 : 2018, ISO 14001 : 2015, ISO 45001 : 2018, ISO 50001:2018, CE, FCC and RoHS, BIS, STQC approved compliance report |
| Power Source | 12 VDC, 3 A ± 10% |
| Power Consumption | Basic: 6.5 W Max.: 17.25 W |
| Operating Temperature | –40 °C to +65 °C |
| Operating Humidity | ≤ 95% (RH) |
| Dimension | 270.4 mm × 160.0 mm |
| Weight | 2400g |
| Weight | 2 kg |
|---|---|
| Brand | CP PLUS |
| Compatibality | Television, Android |
| Power Consumtion | 6.5 W Max.: 17.25 W |
| color | White |
| Warranty | 2 Years |
| RAM Size | 256 MB |
| Resolution | 1920 × 1080, 1280 × 720, 704 × 576, 352 x 288 |
