ARCTIC P14 Pro Reverse 140mm PWM Fan
RAM & SSD prices are highly volatile. Please confirm stock and price before placing your order.
Original price was: ₹5,599.00.₹1,099.00Current price is: ₹1,099.00. (Inclusive of GST)
- Fan Speed: 500–3000 rpm
- Bearing: Fluid Dynamic Bearing
- Static Pressure: 4.50 mm H2O
- Airflow: 73 cfm | 124.03 m³/h
In stock
ARCTIC P14 Pro Reverse 140mm PWM Fan
Feature
.jpg)
Optimized Airflow Design
The trumpet-shaped intake and teardrop-shaped spokes direct the airflow with reduced flow losses.
This reduces air resistance, minimising turbulence and aerodynamic noise.
SOTA Microcontroller
Reduces motor noise, compensates for load fluctuations, and protects against inrush currents and reverse polarity.
.jpg)
More Power – Less Noise
An automated measuring and balancing process ensures smooth performance by applying the balancing compound with pinpoint accuracy.
Minimum Gap Dimensions for Maximum Efficiency
Enables higher static pressure and maximum airflow efficiency.
.jpg)
PST – Easy Cable Management and Synchronized PWM Control
Thanks to the additional ARCTIC P14 Pro Reverse PWM connector, multiple fans can be daisy-chained and controlled simultaneously through a single header.
Optimized FDB Bearing-Shaft Design
A hydrodynamic bearing combined with an extended shaft ensures quieter operation by improving pressure distribution and minimizing vibrations.
| General Specifications | |
| Performance | |
| Fan Speed | 200—1900 rpm PWM Controlled (0 rpm below 5% PWM) |
| Airflow | 68.90 cfm | 117.06 m³/h |
| Static Pressure | 2 mmH2O |
| Noise Level | 0.3 Sone |
| Fan | |
| Fan Frame | Standard |
| Control Type | PWM PST |
| Connector | 4-Pin Connector + 4-Pin Socket |
| Fan Bearing | Fluid Dynamic Bearing |
| Operating Ambient Temperature | 0—40 °C |
| Electric Characteristics | |
| Typical Voltage | 12V DC |
| Starting Voltage | 5V |
| Current | Voltage | 0.17 A | 12 V DC |
| Cable Length | 400mm |
| RGB Specifications | |
| LEDs | 12 A-RGB LEDs |
| Connector | 3-Pin 5 V-DI-GND Connector |
| Current / Voltage | 0.4 A/5 V |
| Cable | 400 mm Cable with 80 mm Sharing Cable, Black |
| Size & Weight | |
| Length | 140mm |
| Width | 140mm |
| Height | 27mm |
| Weight | 225g |
| Warranty | 6 Years |
| Note** | **Prices, Specifications & Features are subject to change without notice |
| Weight | 1 kg |
|---|---|
| Brand | Arctic |
| color | White |
| Warranty | 6 Years |
| Fan Size | 140mm |
| Lighting Type | A-RGB |
| EAN Code | 4895265000775 |
