Arctic P14 Max 140mm High Speed Pwm Cabinet Fan - Green Apple Compunet

Arctic P14 Max 140mm High Speed Pwm Cabinet Fan

Sale!65%

High Performance: Speeds up to 3300 RPM with airflow of 138.5 CFM.
PWM Control: Automatically adjusts speed for efficient, quiet cooling.
Durable Design: Features a hydrodynamic bearing for longevity.
Versatile Use: Ideal for cases, radiators, and heatsinks.

(Inclusive of GST)

Out of stock

SKU: ACFAN00287A

Categories:Arctic Case Fans, Case Fans

Tags:case fan, P14 Max, arctic, CABINET FAN

Brand: Arctic

Guaranteed safe & secure checkout

Description

SPECIFICATIONS

Additional information

Reviews (0)

Q & A

ARCTIC P14 Max – PC Fan, High-Performance 120mm Case Fan, PWM controlled 200–3300 rpm, Optimised for static pressure, 0dB mode, Fluid Dynamic Bearing – Black

Extremely Wide Speed Range

Building up on the success of the P14 PWM, the P14 Max extends the controllable speed to an impressively wide range from 400 rpm up to 2800 rpm. This enables a quiet operation when low airflow is needed and also an unprecedented level of performance on heatsinks and radiators. The P14 Max provides a significant performance boost to existing air and water cooling solutions.

Maximum Performance — Without Compromises

The P14 Max delivers focused airflow and high static pressure, making it suitable for all scenarios. The fan is optimised for use on radiators, heat sinks, pinholes and mesh. Therefore, the P14 Max is the ideal fan for enthusiasts and professionals who are looking for maximum performance with a long service life.

0 dB Mode — Zero rpm

The fan speed can be throttled down to standstill via PWM. This allows silent operation in IDLE and at the same time guarantees maximum performance when required. Thus, the P14 Max allows an incomparably dynamic adjustment of the speed, so that the airflow can be perfectly regulated for every case.

Improved Stability

The P14 Max features a closed fan wheel design. The advantage of this fan wheel combination is a pressure stability without compromise. In scenarios with high pressure resistances and higher speeds, the force effect is distributed uniformly over the entire fan wheel and enables low-vibration rotation while maintaining high static pressure.

Maximum Smoothness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. The rubber pads mounted at the corners additionally dampen the residual vibrations caused by the higher revolutions.

Virtually Silent due Fluid Dynamic Bearing

As a special feature, the P14 Max is equipped with ARCTIC’s proven Hydrodynamic Bearing. This enables the virtually silent operation at low speeds that customers have been asking for. At maximum speed, brute performance is still guaranteed. Although these bearings tend to wear out, ARCTIC does not compromise on durability and still offers the 6-year warranty.

Quality You Can Rely On

To ensure the longevity of our products, we carry out long-term tests under different, sometimes very adverse conditions. In this way, we learn how we can permanently improve our products for our customers. In addition, the excellent results of long-term testing give us the assurance that our products are not only outstanding in terms of quality, but also in terms of durability. This is a certainty that we are happy to pass on to our customers, which is why we give a 6-year manufacturer’s guarantee.

SPECIFICATIONS

General Specification
Dimensions	140 (L) x 140 (W) x 27 (H) mm
Net Weight	245g
Operating Ambient Temperature	0–40 °C
Fan Specifications
Fan Speed	400—2800 rpm (PWM controlled), 0 rpm below 3 % PWM
Airflow	95,00 cfm \| 161,40 m³/h
Static Pressure	4,18 mmH2O
Fan Bearing	Fluid Dynamic Bearing
Typical Voltage	12 V DC
Startup Voltage	3.9 V DC
Current	0.35 A
Cable Length	400mm
Connector	4-Pin PWM Connector
Width	167mm
Height	34mm
Length	167mm
Weight	0.303 Kg
Warranty	6 Years
Note**	**Prices, Specifications & Features are subject to change without notice

Weight	1 kg
Brand	Arctic
Case Fan Pack	Single Pack
color	Black
Fan Size	140mm
RPM	2800 RPM
Lighting Profile	Non RGB
Warranty	6 Years
EAN Code	4895213704328
